AGSS Shredder

Product Introduction

Application Materials

Compressed foam

Lumps

Stretch film

AGSS Single Shaft Shredder

Based on the AGS single shaft shredder, we have enlarged the rotor diameter to better handle high strength materials , such as stretch film and ton bags etc.
AGSS shredder equipped with a powerful swing-type hydraulic pusher.This design effectively prevents blockages, reducing wear on internal guides. Its hydraulic power station is closely integrated with the shredder's chamber, saving space while protecting the hydraulic station and facilitating maintenance. All AGS series models are equipped with an E-type smooth rotor, and the external bearing housing design is based on a hydraulic sieve frame, ensuring safety and reliability with dual practicality.

Product parameters

ITEM		UNIT	AGSS850	AGSS1200	AGSS1500	AGSS2000
Cutting Chamber		mm	840×1570	1120×1570	1400x1570	1960x1570
Rotor Diameter		mm	588	588	588	588
Rotor Speed		rpm	53	53	53	53
Main Motor Power		kW	55	75	90	90*2
Rotor Knives		pcs	60	81	102	144
Stator Knives		pcs	2×3	2x4	2x5	2x7
Hydraulic Ram Power		kW	3.75	5.6	5.6	5.6
Screen Size		mm	40~100	40~100	40~100	40~100
Screen Working Area		mm	800×730	800×1000	800×1290	800x1860
Dimensions	A	mm	2300	2300	2300	2300
	B	mm	1650	1650	1650	1650
	C	mm	540	540	540	540
	D	mm	660	660	660	660
	E	mm	2250	2250	2250	2250
	F	mm	350	350	350	350
	G	mm	2000	2280	2600	3720
